Specifications Model # LB 15 Capacity:        8.6’’ X 8.6’’ X 1/4’’ Approx. wt.:    1,200 lbs.   Photos Read More

  Specifications & Details: -Custom built, engineered & then stamped for proper OSHA regs -5k sticker capacity per shelf with 2X safety factor -5 racks that are 5 X 10 X 132” with 12 shelves per tower -2 racks 5 X 10 X 192” with 18 shelves per tower -7 racks that are 20ft tall… Read More

  Options or Upgrades Smooth-Top High Friction Conveyor Belt Standard Conveyor Bed Smooth-Top High Friction Conveyor Belt (TB) Top Brush Head Assembly (TB) Top Brush Head Assembly *Counter Rotating from First Assembly* Electronic Variable Speed Drive (Brush Head) Conveyor Belt Cleaning Brush 1080000 (40 Grit Top Brush) 1080001 (40 Grit Top Brush) *Counter Rotating from… Read More

Description:

VacuMaster Comfort 90° vacuum lifter with 200kg capacity to lift 90x14x12in HVAC units up to 430 lbs. Ceiling mounted bridge crane with low-profile rail and 2 bridges (extra bridge to allow for 2^nd lifter). Lifter with powered 90° tilt and manual +/- 90° horizontal rotation.

• Dry-running electric vacuum pump, 0.56 HP Electric linear actuator for 90° tilt, 1.2 HP Configured for 460V, 3-phase, 60Hz power.
• VacuMaster bow handle, Pivoting version, 400/600mm
• main beam, 1600mm
• Cross beam, 750mm
• suction cup holder
• flat suction cup, 125mm dia
• 2 speed electric chain hoist Model SCH-M, Capacity: 450 kg
• Control integration kit for hoist
• Suction cup shutoff valves
• Rotation-Horiz-Vm-500-90°

  • Manual horizontal rotation device for VacuMaster allows +/- 90° horizontal rotation of suction cup assembly (main beam, crossbeams & pads)below main lifter frame. Locking mechanism with 3-position detent to limit rotation to 90° left or 90° right (to manage hoses). Mounts between VM basic module and main beam.

Read More

Photos Read More
